- Glass Wool
Glass Wool Roll and Board
-
Green binder
-
Soft to
touch
-
Odourless
-
Formaldehyde free
-
Available in
both roll and
board form
-
Customized sizes
Range
- Roll Board
- Density (kg/m3) : 10 to 48 32 to 120
- Thickness (mm) : 25 to 130 15 to 100
- Width (m) : 1.1 to 1.2 0.6
- Density : 7.5 to 30 1.2
- Available with or without facing
Facings
- Aluminium : FSK, R3035 HD, Aluglass
- Polypropylene : White Metalized Polypropylene
- Tissue : FGT, BGT
- Glass Cloth : WGC, BGC
Basic Information
| Make / Brand | Ecoinsul |
| Material | Resin bonded glass wool |
| Standard / Code | IS 8183 |
Product Performing Criteria
| Parameter | Values | Standards | ||
|---|---|---|---|---|
| Thermal Conductivity (W/m.K) |
Roll: 0.030 to 0.041 at 25oC mean
temperature
Board: 0.030 to 0.034 at 25oC mean temperature |
IS 8183, IS 3346 | ||
| Thermal Resistance at Specific Thickness (m2 K/W) |
|
|||
| NRC | 0.65 to 0.95 | ASTM C-423 / ISO 354 |
General Material Properties
| Parameter | Values | Standards |
|---|---|---|
| Non-combustibility | Non-combustible / Incombustible, Reaction to Fire 'A1' | BS 476 Part 4, IS 8183, EN 13501 |
| Surface spread of flame | NIL, Class 1 | BS 476 part 7 |
| Fire propagation | Class 0, index l <12, sub-index i1 <6 | BS 476 part 6 and 7 |
| Moisture content | Less than 2% | IS 3144, IS 8183 |
| Shot content | NIL | IS 3144, IS 8183 |
| Sulphur / Chloride | Negligible | IS 3144, IS 8183 |
| Mold growth | None | IS 3144, IS 8183 |
| Alkalinity | pH 7 to 10 | IS 8183 |
Certifications and Approvals
| Environment | Fire | Health Safety | Standards Compliance |
|---|---|---|---|
|
|
|
|
|
